Product Details
FOR ELEVATORS
TS EN 81-70 / A1 - part 70:
Accessibility to elevators for people including people with disabilities.
LADDER TYPE FOR DISABLED LIFTS
TS EN 81-40- Section 40:
Escalators and inclined lifting platforms for disabled passengers.
Part 2: It is an accessible systems for sitting passangers, standing users and wheelchair users which moves at an oblique plane.
FOR VERTICAL TYPE DISABLED LIFTS
TS EN 81-41 - Part 41: Vertical lifting platforms for people with mobility impairments
TS ISO 9386-1 "Power-driven lifting platforms for movement disabilities
Rules on safety, dimensions and functional operation
Part 1: Vertical lifting platforms
• Braille alphabet must be on the call buttons.
• Horizontal systems vary from 0,7 m / s to 0,15 m / s.
• Disabled elevators should be preferred in sloping places above 6 degrees.
• All elevators for disabled and elderly people are exempt from VAT.
WLP 300
Technical Information
Areas of Application : Indoor or Outdoor
Load : 300 kg
Speed : Maximum 0.15 m/s
Travel Distance : Maximum 1800 mm
Stop : 2
Operation System : Hold to run system
Drive : Electrical traction, screw&nut system, 2.2 kW motor
Power Supply : 220 V, 1 Phase, 50/60 Hz, 8,5 A
Direction : 360°
Emergency Platform: Automatic
Cladding : Stainless steel or optional sheet; powder-coating in RAL colours possible
WLP 360
Technical Information
Areas of Application : Indoor
Load : 350 kg
Speed : Maximum 0.12 m/s
Travel Distance : Maximum 700 mm
Operation System : Hold to run system
Drive : Electrical traction, screw&nut system, 2.2 kW motor
Power Supply : 220 V, 4 A
Direction : Four side (360°)
Safety Device : Emergency Rescue System
Cladding : Stainless steel
WLP 400
Technical Information
Areas of Application : Indooror Outdoor
Load : 400 kg
Speed : Maximum 0,15 m/s
Travel : Maximum 9000 mm
Stops : Maximum 4
Operation System : Hold to Run Control
Drive : Screw and nut
Power Supply : 220 V, 1 phase, 50/60Hz, 8,5A
Direction : Single line/ 90°/180°
Safety Device : Emergency Rescue System
Cladding : Stainless steel or optional sheet; powder-coating in RAL colours possible or glass (laminated safety glass)
WLP 460
Technical Information
Areas of Application : Indoor or Outdoor
Load : 300 kg
Speed : Maximum 0.12 m/s T
ravel Distance : Maximum 3000 mm
Stop : 2
Operation System : Hold to run system
Drive : Electrical traction, screw&nut system, 2.2 kW motor
Power Supply : 220 V, 1 Phase, 50/60 Hz, 8.5 A
Direction : Single 90° -Opposite (180°)
Safety Device : Automatic
Cladding : Stainless steel or optional sheet; powder-coating in RAL colours possible
